Cable tunnel online monitoring system

With the development of economy, the high and low voltage lines of cities, industrial and mining and national defense construction gradually realize cable entry, and cable tunnels have gradually become the main method of urban power supply. However, tunnels are not like overhead lines, which can be carried out on the map with the naked eye. Inspection and fault finding require assistance based on science and technology, and a comprehensive online monitoring system for cable tunnels is indispensable The cable tunnel online monitoring system is mainly composed of two parts: the front-end device and the back-end monitoring and analysis software. The front-end part monitors the cable body and the tunnel environment through sensors, and transmits the monitoring data to the back-end monitoring and analysis center, so that the relevant department staff can check the tunnel The environment is remotely monitored, and if an abnormality occurs, corresponding maintenance measures can be taken timely and accurately

Keyword:

Power IoT sensors Smart power distribution Internet of Things Smart cable tunnel gallery Smart power generation Internet of Things Smart Internet of Things

Category:

Power transmission IoT sensor

Free consultation telephone:

0519-85851518

Message

Related Products

Current monitoring sensor of arrester in switchgear

Full current measurement range: 0.050 ~ 5.000mA Full current measurement error: ± (standard reading ×1%+5μA) Record the cumulative discharge times :0 ~ 99 times Power supply: DC24V Communication interface: RS-485

Ground resistance sensor

Power supply: dc6 ～ 12V Range: 0.01 Ω- two hundred Ω Accuracy: ± 2%rdg ± 3dgt(20℃ ± 5 ℃, below 70% RH) Communication mode: RS485 Protection grade: IP54

High frequency current sensor

Sensitivity: 5pc Detection frequency band: 50KHz ～ 100MHz Signal output: RS485 Installation position: cable connector ground wire Installation mode: clamp type, clamping

Tilt sensor

Range: ± thirty ° Voltage: 9-35v Output mode: RS485 IP67 protection level

Infrared thermal imaging camera of switch cabinet

Thermal imaging resolution: 160 * 120 Visible light resolution: 200W Power supply: dc12-24 V Temperature range: - 20 ℃ ~ 150 ℃ Accuracy: ± 2 ℃ or 2% of the reading (take the maximum absolute value)

Space UHF PD sensor

Detection frequency band: 300 ~ 1500mhz Protection grade: IP65 Collect the discharge amplitude and phase The service life is more than 8 years

Micro weather sensor

Temperature: measuring range - 40 ~ 60 ℃ ° C Accuracy ± zero point one ° C； two Temperature: measurement range 0 ~ 100% RH Air pressure: measuring range: 10 ~ 1300 Wind speed measurement range: 0-75 M / S

Switch cabinet partial discharge sensor (UHF)

The system adopts UHF principle to conduct local discharge monitoring of high voltage switchgear to ensure the effective monitoring data, and increase system reliability. Ultra low power consumption and 485 bus communication mode are adopted. It is applicable to switch cabinet and ring network cabinet. Each cabinet is equipped with one set to realize the power / qualitative measurement of local discharge. It can be directly connected to the system host without the limitation of host channel.)

Switch cabinet partial discharge sensor (UHF + AE two in one)

The system adopts UHF + AE principle Ultra low power consumption and 485 bus communication mode are adopted, It is suitable for switch cabinet and ring main unit to realize the quantity / qualitative measurement of partial discharge

Intelligent air conditioning / dehumidification linkage device

AC / dc220v power supply is adopted Allowable deviation - 20% ～ + 20% Control output node capacity: AC / dc220v, ≥ 8A Support 2-4 independent node output capability

Intelligent light control unit

Output mode: switch type, realize local and remote control of lighting Wall mounted / 2U rack mounted Using brand devices to ensure reliability Size (mm): 480mm long × 85mm wide × 340mm deep

Intelligent water pump control unit

Output mode: switch type, realize the linkage control of water pump Wall mounted / 2U rack mounted, Using brand devices to ensure reliability Size (mm): 480mm long × 85mm wide × 340mm deep
